1/2″ Case Skid Steer Forestry Door | | Shields

The 1/2″ Case Polycarbonate Forestry Door from Shields is an excellent replacement or upgrade for your Case Skid Steer (compatible models below) for forestry applications and other uses where protection for the operator is needed. This door includes a windshield only, and is designed to fitthe existing frame and mounting holes as standard OEM glass. Check out our skid steer cab enclosures if you need the full frame, latch, and mounting hardware. Shields doors feature milled edges for transferring the door seal with ease.

Made of heavy-duty, super-coated, abrasion-resistant polycarbonate, these doors are rated for forestry mulching, demolition, wood processing, tree shearing and more. NOT RATED for chain shot applications. Shields doors are post-coated with Shields SUPERCOAT™ which provides abrasion resistance. However, using wipers can eventually cause scratching when grit/dirt gets caught on the wiper.

Hardware and Latches/Handles not included. This is not the same product as the Case Brand Forestry Package.

Mounting Details

 Shields doors are designed to be a direct replacement for your standard OEM door and feature the same mounting and hardware holes. The door uses your existing OEM hardware for installation and replacement of your existing door. Purchase of this door does not include mounting hardware or seal. If replacing a 1/4″ or less thickness OEM door with 1/2″ polycarbonate, longer bolts may be required for optimal installation. Please give us a call for details.

The best way to tell which door you need is by looking at your door’s wiper arm. The Dual Wiper arm is a larger wiper and it is attached lower on the door, in the lower section where the door is narrow. It also has two arms that hold the wiper blade. The Single Wiper Arm is mounted slightly higher and to the left when looking at the door from outside.

• Single Arm: Feb 1st 2013 and any prior year: SR130 SR150 SR175 SR200 SR220 SR250 SV185 SV250 SV300 TR270 TR320

  • Replaces OEM Glass: 84344565 & 47405930

• Dual Arm: 2013- After: SR130 SR175 SR200 SR210 SV185 TR270 SR250 SR150 SR220 SV250 SV300 TR320 TV380

  • Replaces OEM Glass: 84344565 & 47405930

Are you replacing OEM polycarbonate? – most of our doors are for placing OEM glass, and if you are replacing OEM polycarbonate for this model, please give us a call before ordering.

• 1/2″ thickness options
• Clear Lexan/Polycarbonate material is impact-resistant
• Easily replaces OEM factory glass
• Supercoated on both sides for optimal abrasion-resistance
• Duplicates OEM mounting holes
• Milled edges make swapping out the door seal fast and easy
• 1/2 the weight of glass
• 260 times stronger than glass
• Noise reducing
• Increases light transmission and visibility
• Reduced summer heat gain
• Reduced winter heat loss
• Hardware not included
